Name: 6209-C3 Ball Bearing 45x85x19mm 6209 C3 OPEN, NO SEALS
Brand: MAPLE ACE
Price: 14.95 CAD
Availability: InStock

Disponibilité: En stock

Type de produit: Ball Bearings

Vendeur: MAPLE ACE

Prix régulier $14.95 CAD

Single-row deep groove ball bearings offer high versatility across various applications. Designed with low friction, optimized for: Low noise Low vibration High...

6209 C3 Deep Groove Ball Bearing dimensions: Bore Diameter 45mm, Outside Diameter 85mm, Width 19mm. 100% Chrome Steel.
Interchange to 6209 C3, 6209/C3, 6209, 6209 CM, 6209 CN
This deep groove ball bearing is Open and has no shield or seal on both sides.
Application: ATVs, Industrial Applications, Food & Beverage, Furnaces, Transmissions, Gearboxes, Elevators, Lifts and Hoists, Sporting Machines, Medical Devices, Automotive, Agriculture Machines...etc
Specializing in the Exclusive Production of Bearings with High Performance, High Speed, Less Vibration, Low Noise, and Long Life.

Description

Single-row deep groove ball bearings offer high versatility across various applications.
Designed with low friction, optimized for:
- Low noise
- Low vibration
- High rotational speeds
Able to support both radial and axial loads in both directions.
Easy to mount and require less maintenance compared to many other bearing types.

Item	6209 C3
Bearing Type	Deep groove ball bearing
Bore Diameter	45.00mm
Outside Diameter	85.00mm
Width	19.00mm
Width Inner Ring	19.00mm
Width Outer Ring	19.00mm
Dynamic Load Rating Cr	35100 N
Static Load Rating Cor	21600 N
Limiting Speed	11000 r/min
Clearance	C3
Tolerance Classes	P5
Cage	Metal
Closures	Without
Lubrication Type	Without
Lubrication Temperature	Without
Rolling Element Indicator	Ball
Material	Gcr15
Product Weight	0.420 KG
